Ohlins RXF34 - Leg Separation and Fluid Drainage

4
RXF34/RXF36 50-HOUR SERVICE
3
4
5
3. Remove the nut by using a socket wrench with a 14 mm deep hex
socket.
4. Use a socket wrench with a 12 mm deep hex socket to remove
the washer and the nut on the lower air valve.
5. Slide the lower legs off the stanchions.
6. Drain the lower legs of all uids.
