Warning!
Before riding, always make sure that the basic settings
are according to recommended Set-up Data. Read
about adjustments and setting up in the shock Owner’s
Manual before you make any adjustments. Contact an
Authorized Specialized Service Centre if you have any
questions about setting up.
Enduro Stumpjumper/
Rhyme
Length 216 197 mm
Stroke 57 47 mm
Rebound 3 3 clicks
Compression low 4 4 clicks
Compression high pos 2 pos 2
Recommended sag 17 12,5 mm
SETUP DATA
MAINTENANCE
Position 3 is for those long climbs where the
need for traction is limited and additional plat
-
form control helps to gain efciency.
If the bicycle feels
• soft
• low
• is bottoming
→ Increase compression damping
If the bicycle feels
• harsh
• hard
→ Decrease compression damping
Maintenance Interval
Clean dirt and debris from shock absorber Every ride
Check air pressure and set sag Every ride
Check torque on shock absorber mounting bolts Every ride
Full shock absorber air spring rebuild at service centre 100 hours/ 1 year
Air pressure
The correct air pressure and sag is along with
the clicks, crucial to nd the best set up that
suits your riding style. Start with basic sag and
go through the adjusters but the adjuster will
not fully compensate for a too soft or hard air
spring.
Note!1
For a more progressive spring characteristics contact an
Authorized Specialized Service Centre.
