Ohlins TTX44 - Spring Preload; Set the Spring Preload

Spring Preload
TPX McPherson
TTX shock absorber
Spring Preload
When adjusting the spring preload
you move the spring seat. This will lower
or raise the vehicle ride height. The ride
height is an important criteria for the
behavior of your vehicle.
Set the Spring Preload
For TTX shock absorber use C-spanner
00710-02 and C-spanner 01796-01 to
undo the lock nut and turn the spring
platform to the desired position.
For TPX McPherson use 2 C-spanners
01796-01 to undo the lock nut and turn the
spring platform to the desired position.
Spring
platform
Spring
platform
C-spanners
5
