1-2.Symbols Explanation
1-3.Schematic Diagram of a completed Scooter
05 06
The signal word that indicates a hazard with a high level of risk which,if not
avoided,will result in death or serious injury.
The signal word that indicates a hazard with a medium level of risk which,if
not avoided,could result in death or serious injury.
The signal word that indicates a hazard with a low level of risk which, if not
avoided, could result in minor or moderate injury.
This symbol marks additional information and explanations with regards to
the product and its use.
This symbol stands for "Conformité Européenne", which means "Conformity
with EU-directives". With the CE-marking the manufacturer confirms that this
product complies with applicable European directives and regulations.
This symbol stands for "tested safety". Products which carry this symbol
comply with the German Product Safety Law (ProdSG).
Read the instruction manual carefully and completely before use.
This product is classified as protection class II.
Permitted maximum speed: 25 km/h.
The product must only be used by persons with a weight of more than 30 kg
and less than 100 kg.
Wear Personal Protective Equipment (PPE).
The product must only be used by one person at a time.
Only use on flat, dry and even surfaces.
Do not use the product after consuming alcohol, sedatives or psychoactive drugs.
Minimum age (user): 14 years
Do not enter roads marked with these signs.
Polarity indication (+) and (-).
DANGER
!
WARNING
!
CAUTION
!
Headlights
Pole clamp
Frame
Front assembly
Front fender
Drum brake
front wheel
Concealed
brake lever
Meter
Bell
Phone holder
Side reflector
FOC controller
Taillight
Rear fender group
Drum brake motor
Pedal pad
Lithium battery pack
Kickstand
Finger throttle
505mm
1220mm
1200mm
Charge port
Min.:30kg
Max.:100kg
