Operation guide
50mm
(2”)
Seat height adjustment
Adjust the seat height using the seat height adjustment
lever on the bottom right of the seat. The seat will be
lowered if you lift the lever while seated, and it will stop
at any position you release the lever at. The seat will be
raised if you lift the lever while not seated on the seat.
mm (inch)
Seat depth adjustment
Adjust the seat depth by sliding the seat forward or
back within a range of 50 mm (2”) using the Seat
slide lever on the bottom left of the seat. This allows
for maintaining an appropriate distance between
the back and the front edge of the seat, reducing
pressure on the back of the knees and providing
reliable support for the lower back.
mm (inch)
130mm
(5 1/8”)
