Installing upgrades> 97
M
EMORY
UPGRADE
The basic printer model comes equipped with 64MB of main
memory. This can be upgraded with an additional memory board
of 64MB or 256MB, giving a maximum total memory capacity of
320MB.
Installation takes a few minutes, and requires a medium size
cross-head (philips type) screwdriver.
1. Switch the printer off and disconnect the AC power cable.
2. Press the cover release and open the printer’s top cover
fully.
3. Lift the front cover latch and pull open the front cover.
4. Remove the screw (1) securing the right-hand side cover.
WARNING!
If the printer has been powered on recently, the fuser
will be hot. This area is clearly labelled. Do not touch.
1
