Clearing paper jams> 106
• To remove a sheet from the central area of the
belt (2), carefully separate the sheet from the belt
surface and withdraw the sheet.
• To remove a sheet just entering the fuser (3), separate
the trailing edge of the sheet from the belt, push the
fuser pressure release lever (4) towards the front and
down to release the fuser’s grip on the sheet, and
withdraw the sheet through the drum cavity area.
Then allow the pressure release lever to rise again.
4
2
3
1
NOTE:
If the sheet is well advanced into the fuser (only a short
length is still visible), do not attempt to pull it back. Follow the
next step to remove it from the rear of the printer.
