Clearing paper jams> 107
8. Starting with the cyan image drum unit nearest the fuser,
replace the four image drums into the drum cavity,
making sure to locate them in the correct order.
• Holding the complete assembly by its top centre, lower
it into place in the printer, locating the pegs at each
end into their slots in the sides of the printer cavity.
1
2
3
4
1. Cyan cartridge 2. Magenta cartridge
3. Yellow cartridge 4. Black cartridge
