1 TROUBLESHOOTING FOR THE HARDWARE
66 Cleaning the Main Chargers and LED Print Heads
14
Press [FINISH].
10
Attach the cleaner with its top on the right and its
holding side on the left.
Check that the cleaner is fixed to the cover.
11
Return the 4 green levers located under the toner
cartridges.
12
Push the waste toner box securely until the upper
latches click taking care not to tilt it.
13
Close the front cover pressing both edges.
12
To Next Page
