Doc No.
Version 1.0
TITLE
Service Manual
LCD TV For 232-S12
Page 4/44
2. Specifications
PRODUCT SPECIFICATIONS
LCD Panel
32" TFT
Power Management
(Standby Mode)
＜ 1W
Displayable Resolution
VGA 1360*768 max.
Pixel Pitch
0.17025mm x 0.51075mm x RGB
LCD Display Color
16.7M colors(8-bits colors).
Viewing Angle
178(H)/178(V) (CR>10)
Response Time
8ms (Gray to Gray)
Active Display Area
697.685mm x 392.256mm (31.51" diagonal)
RF Tuner
Combo RF (NTSC/ATSC)
Power
Voltage : 100~240 V
Consumption : 164W
Speaker
10W
Compliance
FCC, cUL, CSA, Energy Star
Temperature
Operating: -10℃~40℃
Storage: -10℃~60℃
Weight w/o stand
33.63lbs
Weight w/ stand
35.5lbs
Gross Weight
45.421lbs
Dimensions (WxDxH)
37.76 inches x 9.37 inches x 22.20 inches
Carton Dimensions
(WxDxH)
42.80 inches x 12.40 inches x 25.35 inches
