7 0-120 2 Hold-on open time
8 0-3 1 Delay open time
9 0-1 1 Left and right directions of
door opening
A 0-1 1 Fire alarm signal to
open/close door
B 30-200 90 Opening/Closing angle
C 0-30 20 Locking force
D 0-60 20 Opening braking force
E 0-60 20 Closing braking force
Debugging Further introduction:
1.Opening speed, 10-100 adjustable
2.closing speed, 10-100 adjustable
3.The speed of damping opening, 1-10 adjustable
4.The speed of damping closing, 1-10 adjustable
5.Opening damping distance, 1-60 adjustable
6.Closing damping distance, 1-60 adjustable
7. The time from the door opening destination till the door
begin to close, 0-120s adjustable
8.Delay-open time: delay opening time 0-3s adjustable,specially supply time for
electro lock to lock or unlock which is helpful to avoid damage to drop bolt lock.
9. Opening direction (Left or Right)
A. Fire signal open/close: It is only used when connected with fire alarm system.
B. Opening angle adjust: 30-200 adjustable. The digital angle is not the door opening
angle, but the driving axis turning angle; the door opening angle features different
subject to the sliding arm or articulated arm. Users can adjust the digits referring to
the real door opening angle.
C. Locking force 0-30: The force to open the door manually when the door is closing
D. The braking force when the door being fully opened, 0-60 adjustable
E. The braking force when the door being fully closed, 0-60 adjustable
