INSTALLATION
INSTALLATION
5
The picture is for reference only , actual product may vary.
Rear Panel
Connecting to TV using RCA support
Front Panel
Pull USB compartment door as indicated on the front panel.
Connect your removable external drive via built-in USB port when trying to record
programs.
LR
INVIDEO
TV
AUDIO
Antenna
DTR
CONNECT TO AUDIO R/L TO TV OR AUDIO TUNER
COMPOSITE VIDEO BROADCAST SIGNAL
POWER ON/OFF
COMPONENT VIDEO OUTPUT, ANALOGUE, HIGH DEFINITION.
ANT IN: CONNECT TO ANTENNA
LOOP OUT : CONNECT TO ANOTHER RECEIVER
CONNECT TO PC FOR
SOFTWARE UPGRADE
CONNECT TO TV SET HDMI-OUT INPUT
CONNECT TO DIGITAL AMPLIFIER
To Next Page
