46 | Page Oliver Machinery 2019 Lathe
Key
Part Number
Descriptions
Specification
QTY
1
300145-922
Handle
2
2
925226-001
Cover Assembly of Headstock
1
.1
175177-000
Cover
1
.2
361509-000
Pin
1
.3
175178-901
Fix Plate
1
3
002602-107
Cap Lock Screw M6*1.0P*8
M6*1.0P*8 (Black)
1
4
000804-103
Round Head Hex Screw M5*0.8P*10
M5*0.8P*10 (Black)
3
5
361529-901
Bushing
1
6
000202-101
Set Screw M5*0.8P*5
M5*0.8P*5 (Black)
2
7
051509-901
Pulley
1
8
001902-109
Set Lock Screw M6*1.0P*6
M6*1.0P*6 (Black)
2
9
014382-000
Poly-V-Belt
540J-8
1
10
380951-902
Sleeve
1
11
660120-000
Magnetic Ring
1
12
175172-000
Sensor Plate
1
13
006302-100
Spring Washer 5.1*9.3
5.1*9.3 (Black)
2
14
000102-103
Cap Screw M5*0.8P*10
M5*0.8P*10 (Black)
2
15
021004-000
Cable Tie ALT-085S-B
ALT-085S-B (Black)
3
16
491261-000
RPM sensor plate
1
17
000301-201
Pan Head Screw M3*0.5P*6
M3*0.5P*6 Electroplated
2
18
660002-000
Magnet
1
19
051535-907
Faceplate
6” Diameter
2
20
001902-101
Set Lock Screw M6*1.0P*10
M6*1.0P*10 (Black)
4
21
360956-902
Tightening Nut
M35*1.5P
1
22
030202-002
Ball Bearing 6007
6007-Rubber sealed on both sides
1
23
051508-000
Headstock
1
24
000104-111
Cap Screw M8*1.25P*35
M8*1.25P*35 (Black)
4
25
006305-100
Spring Washer 8.2*13.7
8.2*13.7 (Black)
10
26
006001-054
Flat Washer 8.5*20*2.0t
8.5*20*2.0t (Black)
4
27
030203-002
Ball Bearing 6008
6008-Rubber sealed on both sides
1
28
361528-000
Spindle
1
29
012005-013
Key 8*7*80
8*7*80
1
30
922506-001
Spur Center
1
31
000804-107
Round Head Hex Screw M5*0.8P*12
M5*0.8P*12 (Black)
2
32
381506-901
Bracket
1
33
280295-000
Compressed Spring
1
34
011002-110
Spring Pin 4*16
4*16 (Black)
1
35
361507-901
Bolt
1
36
070052-902
Tool Rest
1
37
051036-000
Banjo
1
38
921423-001
Adjustable Clamping Lever
3/8"-16UNC-1"L
1
39
010035-000
S Ring STW-22
STW-22 (Black)
2
40
380946-902
Shaft
2
41
001901-101
Set Lock Screw M5*0.8P*5
M5*0.8P*5 (Black)
1
42
380953-902
Sleeve
1
43
360918-907
Lock Shaft
1
