Oliver 2019 User Manual

2019 Lathe OLIVERMACHINERY.NET 47 | Page
Key
Part Number
Descriptions
Specification
QTY
44
922456-001
Live Center Assembly
1
45
361506-000
Quill
1
46
361505-901
Shaft
1
47
051035-000
Tailstock (S/N 223429-240034)
1
47
051533-000
Tailstock (S/N 240035 -)
1
48
230421-000
Adjustable Clamping Lever (S/N
223429-240034)
M8*1.25P*20L
1
48
230440-000
Adjustable Clamping Lever (S/N
240035 -)
M8*1.25P*40L
1
49
010030-000
S Ring STW-19
STW-19
2
50
240072-000
Handwheel
1
51
230114-906
Handle
1
52
000103-105
Cap Screw M6*1.0P*15
M6*1.0P*15 (Black)
5
53
011003-104
Spring Pin 5*25
5*25 (Black)
1
54
360920-907
Lock Shaft
1
55
130190-000
Sleeve
1
57
001803-102
Cap Screw w/Spring Washer
M8*1.25P*20/8.2*13.7
M8*1.25P*20/8.2*13.7
(Black)
2
58
950898-001
Sub Switch Assembly
1
.1
021309-000
Strain Relief
PGB16-14B
1
.2
251486-615
Switch Box
1
.3
575656-000
Label
1
.4
008002-100
Hex Nut M4*0.7P(7B*3.2H)
M4*0.7P(7B*3.2H) (Black)
5
.5
006001-001
Flat Washer 4.3*10*1.0t
4.3*10*1.0t (Black)
2
.6
006501-100
4.3*8.5(BW-4)
4.3*8.5(BW-4) (Black)
1
.7
570695-000
Ground Label
1
.8
175169-904
Switch Plate
1
.9
575662-000
Sub Switch Label
1
.10
000805-706
Round Head Hex. Screw
M4*0.7P*16
4
.11
490040-000
Starting Bottom 10A 250VAC/7.5A
380VAC
Green (10A 250VAC/7.5A
380VAC) (Diameter 22)
1
.12
000302-103
Pan Head Screw M4*0.7P*10
M4*0.7P*10 (Black)
1
.13
491260-000
Emergency Stop YK-M1-4*(10A 250V)
(7.5A 380V)
Red*ResettableYK-M1-
4*(10A 250V) (7.5A 380V)
1
.14
000801-102
Round Head Hex. Screw
M6*1.0P*12 (Black)
2
.15
006303-100
Spring Washer 6.5*10.5
6.5*10.5 (Black)
2
.16
006001-115
Flat Washer 6.2*13*1.5t
6.2*13*1.5t (Black)
2
.17
175171-000
Switch Bracket
1
.18
021103-100
Cable Clip ACC-3-B
ACC-3-B (Black)
1
.20
000302-102
Pan Head Screw M4*0.7P*8
M4*0.7P*8 (Black)
1
.21
471037-148
Power cord
18AWG*1C*150mm
S13/Black/E21
1
.22
474001-020
Power cord
SJT18AWG*4C*2900mm
1
