Oliver 2019 User Manual

48 | Page Oliver Machinery 2019 Lathe
Key
Part Number
Descriptions
Specification
QTY
59
006303-100
Spring Washer 6.5*10.5
6.5*10.5 (Black)
4
60
006001-115
Flat Washer 6.2*13*1.5t
6.2*13*1.5t (Black)
4
61
021103-100
Cable Clip ACC-3-B
ACC-3-B (Black)
1
62
006001-001
Flat Washer 4.3*10*1.0t
4.3*10*1.0t (Black)
2
63
000302-102
Pan Head Screw M4*0.7P*8
M4*0.7P*8 (Black)
1
65
000105-104
Cap Screw M10*1.5P*35
M10*1.5P*35 (Black)
6
66
006307-100
Spring Washer 10.2*18.5
10.2*18.5 (Black)
10
67
006001-075
Flat Washer 10.3*22*2.0t
10.3*22*2.0t (Black)
6
68
360355-901
Pin
2
69
051507-000
Bed
1
70
380504-901
Lock Ring
2
71
009101-200
Lock Nut 3/4”-10NC*17mm
3/4"-10NC (27B*17H)
Electroplated
2
72
051510-000
Extension Bed
1
75
006001-068
Flat Washer 10*20*2.0t
10*20*2.0t (Black)
4
76
000105-103
Cap Screw M10*1.5P*30
M10*1.5P*30 (Black)
4
77
950921-001
Converter Assembly
2HP*220-
240V*60HZ*3PH*4P*CSA/UL Plug
1
1
950900-001
IN:1PH / OUT:3PH
1
2
453151-010
SJT 12AWG*3C*2300mm(6-20P)
SJT 12AWG*3C*2300mm(6-20P)
1
78
230240-000
Latch
1
79
175175-000
Right Side Cover
1
80
000801-101
Round Head Hex Screw
M6*1.0P*10
M6*1.0P*10 (Black)
6
81
175186-000
Electric Box Cover
1
82
006002-030
Flat Washer 6.5*23*4.0t
6.5*23*4.0t Electroplated
1
83
251075-615
Foot
1
84
006003-114
Flat Washer 6.4*16*1.6t
6.4*16*1.6t
1
85
000801-112
Round Head Hex Screw
M6*1.0P*25
M6*1.0P*25 (Black) full thread
1
86
175217-000
Cip Guard
1
87
000103-103
Cap Screw M6*1.0P*12
M6*1.0P*12 (Black)
4
88
200119-000
Sponge
1
89
491255-000
Fan
AC220V
1
90
175216-000
Fan Bracket
1
91
000303-803
Pan Head Screw M5*0.8P*10
M5*0.8P*10 Black zinc plated
4
92
230297-615
Fixed Chain
2
93
175182-000
Dust Cover
1
94
491259-000
KE-22DS*110-230V AC
White*KE-22DS*110-230V AC
1
95
000302-103
Pan Head Screw M4*0.7P*10
M4*0.7P*10 (Black)
1
96
006501-100
4.3*8.5(BW-4)
4.3*8.5(BW-4) (Black)
1
97
008002-100
Hex Nut M4*0.7P(7B*3.2H)
M4*0.7P(7B*3.2H) (Black)
1
*98
WT03-10
Label Assembly
1
99
230403-000
Foot Screw
6
