Oliver 2019 User Manual

2019 Lathe OLIVERMACHINERY.NET 49 | Page
Key
Part Number
Descriptions
Specification
QTY
100
175173-000
Left Stand
1
101
021806-000
Easy Fit Grommet
SB-38
1
102
000802-101
Round Head Hex Screw M8*1.25P*16
M8*1.25P*16 (Black)
2
103
020003-000
Strain Relief R-Type SB7R-3
SB7R-3
2
104
174285-904
Strain Relief Mounting Plate
(M6)
1
105
000304-101
Pan Head Screw M6*1.0P*8
M6*1.0P*8 (Black)
2
106
020005-000
Strain Relief R-Type SB8R-3
SB8R-3
1
108
000804-101
Round Head Hex Screw M5*0.8P*8
M5*0.8P*8 (Black)
4
109
950904-001
Front Control Panel Assembly
1
.1
491262-000
Two Position Selector Switch KB2-
ED21/Connect-KB2-BE101(1A)
KB2-ED21/Connect - KB2-
BE101(1A)
1
.2
491263-000
Stop Switch YS-F1-4*(10A 250V) (7.5A
380V)
Red*YS-F1-4*(10A 250V)
(7.5A 380V)
1
.3
490040-000
Starting Bottom 10A 250VAC/7.5A
380VAC
Green (10A 250VAC/7.5A
380VAC) (Diameter 22)
1
.4
300133-911
RPM Knob
1
.5
001904-104
SET Lock Screw
M4*0.7P*8L (Black)
1
.6
000301-101
Round Head Phillips Screw
M3*0.5P*6 (Black)
4
.7
330071-000
Hex. Copper bolt
M3*0.5P*8L
4
.8
491247-000
LCM Display
1
.9
000301-111
Round Head Phillips Screw
M3*0.5P*4 (Black)
4
.10
471037-146
Connect cord
18AWG*1C*150mm
3/Black/E21
1
.11
471037-147
Connect cord
18AWG*1C*150mm
3/Black/E14
1
.12
471037-139
Connect cord
18AWG*1C*400mm
L1/Black/X1
1
.13
471037-140
Connect cord
18AWG*1C*400mm L2/白
/X2
1
.14
473048-010
Connect cord
24AWG*3C*1300mm
1
.15
471037-152
Connect cord
18AWG*1C*500mm*
(Black)(F1)
1
.16
925225-001
Control Plate
1
.17
471037-153
Connect cord
18AWG*1C*500mm*
White(F2)
1
110
361508-901
Knockout Rod
1
111
172894-902
Open Wrench
1
112
021809-000
Clip Ring SB-50
SB-50
5
113
175170-000
Tool Rack
1
114
006001-038
Flat Washer 8*16*1.6t
8*16*1.6t (Black)
2
115
000104-106
Cap Screw M8*1.25P*20
M8*1.25P*20 (Black)
4
116
009005-200
Hex Nut 5/16”-18NC (12.7B*6.75H)
5/16”-18NC (12.7B*6.75H)
Electroplated
6
117
006002-056
Flat Washer 8.5*23*2.0t
8.5*23*2.0t Electroplated
6
118
200120-000
Sponge
1
119
175183-000
Bracket
1
