Oliver 2019 User Manual

50 | Page Oliver Machinery 2019 Lathe
Key
Part Number
Descriptions
Specification
QTY
120
175184-000
Stand
1
121
003801-107
Screw 5/16”-18NC*3/4"
5/16”-18NC*3/4” (Black) (Head
Diameter 18)
6
122
006001-136
Flat Washer 12.2*23*2.0t
12.2*23*2.0t (Black)
4
123
008311-100
Lock Nut M12*1.75P(19B*12H)
M12*1.75P(19B*12H) (Black)
2
124
000005-111
Hex. Screw M12*1.75P*30
M12*1.75P*30 (Black)
2
125
175179-904
Bracket
1
126
001501-101
Cap w/Spring Washer w/Flat
Washer
M8*1.25P*20/8.2*13.7/8.5*19*2t
M8*1.25P*20/8.2*13.7/8.5*19*2
t (Black)
4
127
008306-100
Lock Nut M8*1.25P(13B*9H)
M8*1.25P(13B*9H) (Black)
2
128
175176-008
Motor Plate
1
129
250123-615
Handle
1
130
006001-081
Flat Washer 10.5*27*2.0t
10.5*27*2.0t (Black)
1
131
230343-000
Universal Handle
1
132
175181-904
Bracket
1
133
901360-001
Motor Assembly
2HP*220-240V*60HZ*3PH*4P
1
1
960058-001
Motor
2HP*220-240V*60HZ*3PH*4P
1
.1
606166-000
Motor
2HP*220-
240V*60HZ*3PH*4P*6A
1
.2
589057-000
Motor Label
2HP*220-240V*60HZ*3PH*4P
1
.3
012202-006
Key 5*5*50
5*5*50
1
2
381486-901
Motor Pulley
1
3
001902-109
Set Lock Screw M6*1.0P*6
M6*1.0P*6 (Black)
1
4
001902-102
Set Lock Screw M6*1.0P*8
M6*1.0P*8 (Black)
1
5
023705-011
Strain Relief PGB13.5-12B
PGB13.5-12B (with nut)
1
151
043714-000
O Ring FKM AS026
FKM AS026
1
152
200039-615
Pad
2
153
361527-901
Positioning Pin
1
154
330008-000
Nut
1
155
001903-105
Set Lock Screw M8*1.0P*8
M8*1.0P*8 (Black)
4
156
175233-000
Plate
2
157
000003-102
Hex. Screw M8*1.25P*16
M8*1.25P*16 (Black)
4
158
006001-049
Flat Washer 8.5*16*2.0t
8.5*16*2.0t (Black)
4
159
003902-201
Wood Screw 3/8"-16NC*4"
3/8"-16NC*4" Electroplated
4
160
290031-902
Shoulder Screw
4
161
010014-000
S Ring
STW-35
1
162
006714-100
Wave Washer
BWW6305(47.2*60.2) (Black)
1
