0641S20004 2-2
DESCRIPTION/SPECIFICATIONS (Continued)
NOTE
Standard Electrical Options: (Others consult factory).
½ HP, 1 phase, 60 hz, 115VAC, 7 Amps.
½ HP, 1 phase, 60 hz, 230VAC, 3.5 Amps.
½ HP, 1 phase, 50 hz, 220VAC, 3.5 Amps.
Standard Product Width Capacity
14”, 17”, & 21”
Shipping Weight
14”: 212 lbs. (95 kg) (approximate)
17”: 227 lbs. (102 kg) (approximate)
21”: 257 lbs. (116 kg) (approximate)
Height
Bench Top: 21” (533 mm), (all widths) (approximate)
On Optional Stand: 54” (1372 mm), (all widths) (approximate)
Bench Space (All Dimensions are Approximate)
14”: 30” (762 mm) X 33” (838 mm)
17”: 33” (838 mm) X 33” (838 mm)
21”: 37” (940 mm) X 33” (838 mm)
Options
33” High Metal Stand with 3” Casters.
Above specifications subject to change without notice.
