Olivieri ERGOFLAM IDRO - Removing the Rear Door Panel

Page | 33
Figure 2.8: Removing the rear door panel
4. Remove the vent grille and display support on top of the heater. Then remove
the screws shown in figure 2.9.
" Take care when moving the front support in order to avoid damaging or
disconnecting the flat connecting cable between the board and the
display.
Door rear panel
Door front ma
j
olica
