9
Command Panel Models (1)
Instruments Control Panel (2):
* The pneumatic brake valve of the flex arm is an optional item that is available when the system does not have
the capacitive system.
Blue Touch Panel with X-Ray Viewer
2 - Backrest Up/Position 2
3 - Seat Down/Position 3
4 - Backrest Down
5 - Work Position
7 - Spittoon Bowl Flush
8 - Cup Filler
9 - On/Off Operating Light
10 - X-Ray Viewer
1 - Electrical Micromotor Speed Control
2 - Electrical Micromotor Direction Control
3 - Scaler Power Control and Function Selector - General-Perio/Endo
4 - Scaler Water Control
5 - On/Off Thermo Comfort LED
6 - Optical Fiber Water Control
7 - Brushless Micromotor Water Control
8 - Pneumatic Brake Valve*
