Olsen Flex Quality - Working Table Quality Cross Flex

10
5.4.2 - Working Table Quality Cross Flex
1 - Top Panel Cross
2 - Command Panel
3 - Instruments Control Panel
The layout of the controls and panels may
vary according customer order and
available handpieces.
These controls are provided below the instrument to which they refer.
1 - Seat Up/Position
2 - Backrest Up/Position
3 - Seat Down/Position
4 - Backrest Down
5 - Work Position
6 - Zero Position
Command Panel (2):
7 - Spittoon Bowl Flush
8 - Cup Filler
9 - On/Off Operating Light
10 - On/Off Optical Fiber Light
11 - On/Off Air Jet System
12 - On/Off Thermo Comfort System
1 - X-Ray Viewer
2 - On/Off X-Ray Viewer
Top Panel Cross (1):
1 - Electrical Micromotor Speed Control
2 - Electrical Micromotor Direction Control
3 - Scaler Power Control and Function Selector - General-Pério/Endo
4 - Scaler Water Control
5 - Optical Fiber Water Control
Instruments Control Panel (3):
