69. Position and attach Right Door (4O) as per Steps 67-68. Door position may need slight
adjusting to open and close correctly. When satisfied, complete all 2” Black Headed Screws (Part I)
Note, Do not over tighten hinge screws when using screw gun.
70. Attach Above Door Trim -
1/2” x 1 1/4” x 64” (Part 4Q) with 6 - 1 1/2”
Finishing Nails (Part F).
Leave small gap to allow for proper door
opening and closing.
Above Door Trim
71. Attach Horizontal Door Stop - 1 1/2” x 2 1/2” x 64”
(Part 4R) with dado facing out, tight against door header.
Align so Dado cut is flush with Header leaving
approximately a 1” overhang in the doorway. Attach with
6 - 2” screws (Part E).
Hor. Door Stop with Dado cut
Inside of Shed
