OLT 6x6 Maximizer - Installing Door Threshold, Flange, and Brackets; Attaching Interior Cane Bolt

75. Attach Interior Cane Bolt (Part M) to vertical door
flange with 3/4” Black Headed Screws (Part J).
Drill 1/2” Diameter Hole
to accommodate rod of
Cane Bolt
Threshold
73. Attach Interior Door Flange -
1/2” x 2 1/2” x 71” (Part 4T).
Position on inside door frame (left
door from outside) using 6 - 2”
screws (Part E).
Position on inside edge of door frame
so flange overlaps door frame by 1”.
Door Flange
72. Attach Door Threshold - 3/4” x 2 1/2” x 62 1/2”
(Part 4S) with 4 - 2” screws (Part E).
74. Attach front Front Triangular Corner
Brackets - 1 1/2” x 5 1/2” x 5 1/2”
(Part 2G) to header and wall frame with
2 - 2 1/2” screws (Part B) per piece.
Toll Free 1-888-658-1658 www.outdoorlivingtoday.com sales@outdoorlivingtoday.com
Page 31
