Page 14
23. Locate Part H - Rear Wall Top Caps -
1 1/2” x 5 1/2” x 44 1/2”. Position and
attach as per Step 20. Once again, the Cap
is designed with tolerance and gaps will
appear around the notches. Later,
caulking may be applied to seal these gaps.
Complete remaining Side Wall Top Cap
attachments as shown to the left.
Rear Wall Top Caps
Outside Angle Cut
Polygal Window
24. Locate Part K - Outside Angle Cut Polygal Windows - 26 1/2” wide. Peel protective
plastic layer off first sheet noting correct side out. On a step ladder, lift window up and position
in the top Corner Post dado cut and in the gap of the Doorway Post. Slide down.
position in dado cut.
position in gap.
Important:
Install Polygal Windows in
sequence outlined in this manual.
