Page 31
67. Locate Parts FF & GG - Outside Post Trim Narrow- 1/2” x 4 1/2” x 34 7/8” and Outside Post
Trim Wide - 1/2” x 5 1/2” x 34 7/8”. Position with Wide Trim capping the side when looking at the front.
Align Trims so flush under Wall Top Caps and attach with 4 - 1 1/4” finishing nails per piece.
Wide
Narrow
68. Complete remaining Outside Post Narrow and Wide Trims.
69. Locate Part HH -Vertical Wall
Trim - 1/2” x 3 1/2” x 34 7/8”. Position
underneath Top Wall Cap where Walls
attach to Posts. Center and attach with
4 - 1 1/2” finishing nails per piece.
To Next Page
