8. At this stage, your
gazebo floor should look
similar to the illustration to
left.
Toll Free 1-888-658-1658 www.outdoorlivingtoday.com sales@outdoorlivingtoday.com
Page 6
9. Locate and position a Mid Floor Joist (42 3/8” long) and an Interior Core Brace (12” long). Make
sure the longer side of Core Brace is flush with the end of the joist and attach together with 2 - 3”
screws. Once again, make sure Core Brace is centered and flush with joist. Complete all 8 attachments.
Interior Core Brace
(angle cut on ends)
12” long
Mid Floor Joist
10. Set completed Mid Joist / Core Brace
Assembly between the main Joist
Assemblies but do not attach.
Important: To confirm
Doorway location, refer
to Step 16.
To Next Page
