Page 7
12. Locate 3 1/2” x 3 1/2” Posts. Align
first Post with four drilled holes in bottom
aligned with “T” Post Mount Plates.
Important: Be sure to align Post so top
angle cut is high to the inside.
Angle Cut of Post
(high side = inside)
11. Position remaining Mid Joist / Core Brace Assemblies
roughly between the main Joist Assemblies. Some adjusting
will be necessary to form a symmetrical pattern.
4 Holes Drilled
in bottom of
each Post
Do not
attach until
Step 22.
To Next Page
