Page 16
30. Repeat Step 29 but attach Horizontal Extender Wall Braces (3/4” x 3 1/2” x 20 1/4”/65 3/4”) to lower
part of walls approximately 27” up from the floor but offset the seams from previous braces. Attach with
5 - 1 1/4” screws.
27”
29. Attach Horizontal Wall Extendor Braces (3/4” x 3 1/2” x 20 1/4”/65 3/4”) to Framing of Side Walls
on the high side to further secure walls together. Position 72 1/2” up from floor or 1/2” below extendor wall
framing. Fasten each piece to wall studs as illustrated above using 5 - 1 1/4” screws.
72 1/2”
1/2” below extender
wall framing.
To Next Page
