Owner’s book • 01 Moca 1514
This Manual is only for skilled personal.
This Manual describes the process of reajusting the adjusting
range of the grind coarseness for the Moca Grinder. Please
notice that this is an intervention in the functions of the ma-
chine. Disconect the power before you begin!
1. Pull the aluminium cap off from the adjustment knob.
2. Unscrew the M3×20 Screw in the middle.
3. Pull the adjustment knob from the axis. If you want to
adjust the range finer, turn the knob a half turn counter
clockwise and put it back on the axis. If you want to adjust
the range coarser, turn the knob clockwise.
4. Put the M3x20 Screw back in and tighten it with 1.25 Nm of
force.
5. Put the aluminium cap back on the adjustment knob.
The procedure can be done several times.
Please control before the first operation after the procedure
that the motor is running freely and isn’t blocked.
Manual for reajusting of the Moca SD
1.
3.
2.
4. 5.
