12
Overview of Devices
The diagrams on Page 2 illustrate the walkie-talkie devices in detail. Familiarise yourself with the walkie-talkies
before putting them into operation.
Overview of Operating Elements
1 Antenna 8 Display
2 Push-to-Talk key
PTT
9 Navigation key
3 Menu key 10 On/Off key
4 Call signal key 11 Channel scan key
5 Loudspeaker 12 Navigation key
6 Microphone 13 Charge contacts
7 Headphone socket
Overview of Display Symbols
14 Volume 20 Automatic switch-off
15 Channel 21 Battery capacity indicator
16 Signal being sent 22 Subchannel (Subcode)
DCS
17 Signal being received 23 Channel scan
18 Dual watch
24 Call signal on
19 VOX mode 25 Key lock activated
Overview of Charging Cradle
26 LED (charging process)
27 Power adapter socket
Safety Instructions
Read the operating manual carefully and
proceed as described. Keep the operating
manual close to hand for future reference.
Avoid any personal injury by paying attention to the
following information!
Warning! The walkie-talkies can be
used by children from eight years of age and
by persons with restricted physical, sensory
or mental capabilities or a lack of experience
and/or knowledge when they are under supervision or
have been instructed with regard to safe use of the
walkie-talkies and have understood the potential risks
which result if the instructions are ignored. Children
