Olympus AS-2300 - Connecting the RS25;RS26 Foot Switch; Connecting to a USB Port; Connecting to a Serial Port; Foot switch setting

13
................................................................................................................................................................
Note
The RS25/RS26 foot switch works only with the DSS Player.
Connecting the RS25/RS26 Foot Switch
Connecting to a Serial Port
1
Connect the foot switch cable to
the serial adapter cable.
2
Connect the serial adapter cable to
the PC’s serial port.
Foot switch setting
3
Start the DSS Player and select
“Foot Switch Settings...” from the
“Tools” menu.
4
Select the foot switch connection
method.
12
1
2
USB adapter
Serial adapter
Windows Macintosh
Connecting to a USB Port
1
Connect the foot switch cable to
the USB adapter cable.
2
Connect the USB adapter cable to
the PC’s USB port.
Windows
Connecting the RS25/RS26 Foot Switch
