SPECIFICATIONS CV-160
1-2
Item Specification
2. Light control output signal 2. Output signal level
The output signal level for the automatic light control of an
applicable light source is defined by the following input
standard.
1. Type
(1) 100V class: North America (OAI), Asia 1 (OLA)
(2) 200V class: Europe (OE), Asia 2 (OLA)
2. Rated voltage and input current
(1) 100V class: 100 to 120V, 1.0A
(2) 200V class: 220 to 240V, 0.5A
3. Voltage fluctuation
• The unit performance shall be guaranteed within ±10% of
the rating.
• The unit operation shall be guaranteed within ±15% of the
rating and the temperature increase in ordinary operation
of IEC.
4. Frequency
• 50/60Hz
5. Frequency fluctuation
• The unit performance shall be guaranteed with ±1Hz of
the rating.
6. Power consumption
• 240VA
3. Input/output conditions
3. Power supply
7. Power cable
(1) 100V class (3 ±0.05m cord set)
3-pin hospital grade plug
(2) 200V class (3.2m cord set)
3-pin plug-less with uneven end
(Attach an appropriate plug in the destination.)
Input signal [mV]
F 30 or more
1 15
2 12.6
3 10.8
4 9.1
5 7.5
6 6.3
7 5.4
8 4.5
9 3.8
10 3.2
11 2.7
12 2.3
13 1.9
14 1.6
15 1.4
16 1.2
17 0.95
