ESG-150 (Electrosurgical Generator)
Quick Reference Guide
ESG-150 System Operating Steps
If the red neutral electrode lights
up and alarm tone sounds:
• Is the neutral electrode correctly
connected to the device?
• Does the neutral electrode have
sufficient contact to the skin?
Correct = Green Error = Red
Monitor Neutral Electrodes: Contact Quality Monitor.
Connect device in appropriate receptacle.
7
8
Bipolar Devices
Monopolar Devices
Neutral
Electrodes
