Olympus OM-1 User Manual

10.
The
shutter
releasing
position
of
the
button
too
deep
or
too
shallow.
Excessive
or
insufficient
leeway
in
the
button
motion
after
the
shutter
release.
1)
Improper
adjustment
of
CA9068
(Collar).
9068
should
be
adjusted
so
that
the
mirror
commences
its
operation
when
the
distance
between
the
oblong
hole
of
8862
and
8864
at
their
edges
is 0.3~
0.5.
CAB8862
Checkup
o
Make
sure
9065
does
not
hit
8432
(Hook)
prior
to
or
during
the
film
advancing
motion.
Taking
the
upper
edgesurface
pf
9083
as
the
basis,
the
shutter
should be released
within 0 20:2.
11.
Heavy
touch
of
the
Shutter
Release
Button
1)
Operation
of
CA9078
(Plate)
2)
Releasing
force
of
the
CA8432
(Hook)
too
heavy.
Checkup
o
The releasing force of (8432) should be 50 gr. or below.
