EN 13
En
Using the fiber cable adapter
The fiber cable adapter is required when connecting the separately
available UFL-1 underwater flash to the Case using an underwater optical
fiber cable (optional: PTCB-E02).
How to install
1 Attach the optical fiber cable adapter to the diffuser shown in the figure
below.
2 Put the underwater optical fiber cable plug all the way into the optical
fiber cable (optional: PTCB-E02) insertion slot.
Remove the underwater optical fiber cable when you do not use it while
taking picture.
Memo:
RC mode can use only µ TOUGH-8010/STYLUS TOUGH-8010.
When UFL-2 is used, set camera and UFL-2 to RC mode.
For details, see the instruction manual of digital camera and UFL-2.
PT-048_EN.book Page 13 Friday, December 11, 2009 4:37 PM
