Olympus PT-EP14 - Installation of the Diffuser (Optional); Using the Diffuser; Removing Diffuser (with Port Adapter) from the Lens Port

EN 35
EN
Installation of the diffuser (optional)
Using the diffuser
When using the flash supplied with the camera, attach the diffuser.
Use a diffuser compatible with the lens port.
1 Attach the diffuser to the port adapter.
2 Install the strap of the lens port to the Case body.
3 Install the diffuser on the lens port.
Removing diffuser (with port adapter) from the lens port
To remove the diffuser, pull the port adapter from the
lens port.
Diffuser
Port adapter
