1 The SC180 color camera
5
1.2 Intended use
This camera is intended to be used for the acquisition of digital images, but not for
clinical diagnostic purposes.
1.3 Specifications
Properties of
the SC180
The SC180 is a CMOS color camera with a high frame rate. It was specially devel-
oped for acquisitions using light microscopy. The camera is of a compact design and
can be connected to all common types of light microscope by a C-mount. The ICC
profile technology guarantees an optimal color mapping.
Binning modes
The SC180 has several binning modes. In binning mode, the camera's CMOS
sensor combines neighboring pixels into pixel blocks. This results in a higher
sensitivity and a shorter processing time, but also in a lower resolution.
Technical data SC180
Chip type CMOS
Chip size 1/2.3 inch
Effective area (width x height) 6.140 mm x 4.605 mm
Pixel size 1.25 µm x 1.25 µm
Maximum resolution 4912 x 3684 pixels (4:3)
4912 x 2762 (16:9)
Bit depth 24 bit, 48 bit
Read-out speed 96 – 432 MHz
Interface USB 3.0
Camera mount Standard C-Mount
Acquisition mode Image
format
Resolution Max. frame rate Exposure times
Maximum resolution 4:3 4912 x 3684 pixels 10 frames per second 0.025 ms - 1 s
Binning 2x2 4:3 2456 x 1842 pixels 23 frames per second 0.022 ms - 1 s
Binning 4x4 4:3 1224 x 920 pixels 45 frames per second 0.022 ms - 1 s
Maximum resolution 16:9 4912 x 2762 pixels 14 frames per second 0.025 ms - 1 s
4K 16:9 3840 x 2160 pixels 25 frames per second (8 bit) 0.02 ms - 0.7 s
Full HD 16:9 1920 x 1080 pixels 31 frames per second 0.02 ms - 1 s
Binning 4x4 16:9 1224 x 688 pixels 59 frames per second 0.02 ms - 1 s
