Olympus TG-860 - Shooting Preparations; Battery and Card Handling

5 EN
Preparations for shooting
Inserting and removing the battery and card
1
Follow Steps 1, 2 and 3 to open the battery/card
compartment/connector cover.
• Turn off the camera before opening the battery/card compartment/
connector cover.
3
2
1
Battery/card compartment/connector cover latch
Battery/card compartment/connector cover
Battery/card compartment/connector cover lock
2
Insert the battery while
sliding the battery lock knob
in the direction of the arrow.
• Insert the battery as illustrated
with the C mark toward the
battery lock knob.
• If you insert the battery in
the wrong direction, the
camera is not turned on. Be
sure to insert it in the correct
direction.
• Slide the battery lock knob in
the direction of the arrow to
unlock, and then remove the
battery.
Battery lock knob
