Olympus VG-110/D-700 - Names of Parts; Camera Unit Components

8
EN
Names of Parts
Names of Parts
Camera unit
2
3
1
4
7
5
6
8
9
1 Connector cover
........................ p. 14, 16, 45
2 USB connector
........................ p. 14, 16, 45
3 Strap eyelet .................... p. 9
4 Battery/card compartment
cover ........................... p. 12
5 Flash ............................. p. 31
6 Self-timer lamp ............. p. 32
7 Lens ........................ p. 57, 71
8 Microphone ............. p. 36, 39
9 Tripod socket
