Olympus VG-160 - Camera Parts Identification; Camera Unit Overview

8
EN
Names of Parts
Names of Parts
Camera unit
3
1
2
4
7
6
5
8
9
10
1 Multi-connector
.................. p. 14, 16, 44, 47
2 Connector cover
.................. p. 14, 16, 44, 47
3 Strap eyelet .................... p. 9
4 Battery/card compartment
cover ........................... p. 12
5 Flash ............................. p. 30
6 Self-timer lamp ............. p. 31
AF illuminator ............... p. 36
7 Lens ........................ p. 59, 73
8 Microphone ............. p. 36, 38
9 Speaker
10 Tripod socket
