Names of Parts
Names of Parts
Camera unit
5
2
1
3
4
10
11
9
8
7
6
1 Connector cover
*1
......... p. 44
2 HDMI mini connector
*1
.................................... p. 44
3 Strap eyelet .................... p. 9
4 Multi-connector
............ p. 14, 16, 44, 46, 48
5 Battery/card compartment
cover ........................... p. 12
6 Flash ............................. p. 30
7 Self-timer lamp ............. p. 31
AF illuminator ............... p. 37
8 Microphone ............. p. 37, 39
9 Lens ........................ p. 60, 73
10 Tripod socket
11 Speaker
*1
VR-330/D-730 only
