OMA 526 - Wiring Diagrams and Hydraulic

SCHEMI ELETTRICI ED OLEODINAMICI WIRING DIAGRAMS AND HYDRAULIC
11
Rif.
Ref.
Descrizione Description Marca
Brand
Art.
Article
Qt.à
Q.ty
C1- C2 C1-C2 Elet tro ma gne te Elec tro ma gnet WAR NER TT10 24VAC 50Hz 2
ETV C3 Elet tro val vo la So le noid val ve OIL SISTEM 24VAC 50/60Hz ED100% 1
F1 FU1-FU4 Po ra fu si bi le Fuse carrier WEBER PCH10x38+CH10x38 3
F3 PTC Li mi ta to re di temperatura Ther mal limiter Inte gra to nel mo to re / Inte gra te in the mo tor 1
FC5 QM5 Mi cro i ter rut to re sa li ta Lift mi cro switch PIZ ZA TO FR654 1
IG QS In ter rut to re ge ne ra le Mas ter switch SPRE CHER LA2-12-1754+LFS2-N-6-175+LA2-12
-C4+LA2-G2853+LA2-G3194
1
K1 KM1 Te le rut to re Con tac tor TELEMECANIQUE LC1K0910B7 24V 50/60Hz 1
K2 KA2 Te le rut to re discesa De scent con tac tor TELEMECANIQUE LC1D12+LA1DN11 1
M M Mo to re elet tri co Elec tric mo tor 230/400V 50Hz 1
SB1 SB1 Pul san te sa li ta Up but ton TELEMECANIQUE HB7EA21P (1NO) 1
P2 SB2 Pul san te di sce sa Down but ton TELEMECANIQUE HB7EA21P (1NO) 1
P3 SB3 Pul san te sta zio na men to Stop ping but ton TELEMECANIQUE ZB5AA8+ZB5AZ009+ZBE101 (1NO) 1
QM1 FR2 In ter rut to re ma gne ti co Ma gne tic switch 20A TYPE C 1
S1 - S4 QM1/QM4 Mi cro i ter rut to re fune Ca ble mi cro switch PIZ ZA TO FR1454 4
TR TM Tra sfor ma to re Tran sfor mer C.E. 230-400/24V 300VA 50/60Hz 1
Mor set ti li nea Line clamps CABUR CBD2 2.5mmq 4
Mor set ti ter ra Earth clamps CABUR TE4/D-TE4/0 4mmq 1
