OMA 526BLV - Vehicle Specifications

TIPIDIVEICOLISOLLEVABILIEINGOMBRI
Ipontisollevatorisiadattanopraticamenteatuttiiveicolidipeso
nonsuperiorea4000kgelecuidimensioninoneccedanoquelle
riportatediseguito.
DIMENSIONIMASSIMEDEIVEICOLIDASOLLEVARE
Lalarghezzanondeveeccederei2400mm.
Ilpassotragliassinondeveeccederei3000mm.
Ladistanzamassimatraibordiesternideipneumatici,compresoil
rigonfiamentoaterra,nondeveeccederei2000mm.
Ladistanzaminimatraibordiinternideipneumatici,compresoilri
-
gonfiamentoaterra,nondeveessereinferiorea900mm.
L’altezzaminimadaterrapuòinterferireconlestrutturedelsolle
-
vatore.
Fareattenzionesoprattuttoalleautovetturesportive.
Eventualicarrozzatispecialipossonoesseresollevatitenendoperò
contodellaportatadelsollevatore.
Anchelazonadirischioperlepersonedovràessereadeguata
alledimensionispecialidelveicolo.
Glischemiseguentiriportanoicriteriperdefinireilimitidiimpiego
delsollevatore.
Fig.13 Misureminimeemassime
PERINGOMBRIMAGGIORIVERIFICAREILCARICOMASSIMO
EDILSUOSBILANCIAMENTO
PESIMASSIMIDEIVEICOLIDASOLLEVARE
Fig.14 Ripartizionepesi“A”
Fig.14 Weightdistribution“A”
TYPESOFVEHICLESSUITABLEFORBEINGLIFTEDAND
OVERALLDIMENSIONS
Liftsaresuitableforvirtuallyallvehicleswithtotalweightofno
morethan4000kgandwithdimensionsnotexceedingthebelow
data.
MAXIMUMDIMENSIONSOFVEHICLESMAINLIFTED
Max.width:2400mm.
Max.wheelbase:3000mm.
Max.distancebetweenouterwalloftyres,inclusiveofbulgecau
-
sedbyweightofvehicleonground:2000mm.
Min.distancebetweeninnerwallsoftyres,inclusiveofbulgecau
-
sedbyweightofvehicleonground:900mm.
Caution:thelowerpartsofthevehicleunderbodycouldinterfere
withstructuralpartsofthelift.
Takeparticularcareinthecasesports-cars.
Theliftwillalsohandlecustomisedornon-standardvehiclesprovi
-
dedtheyarewithinthemaximumspecifiedcarryingcapacity.
Alsothepersonneldangerzonemustbedefinedinrelationto
vehicleswithunusualdimensions.
Thefollowingdiagramsillustratecriteriausedtodefinetheopera
-
tinglimitsofthelift.
Fig.13 Maximumandminimumdimensions
FORLARGERDIMENSIONSCHECKTHEMAXIMUMLOAD
ANDPOSSIBLEUNBALANCE
MAXIMUMWEIGHTSOFVEHICLESBEINGLIFTED
Fig.15 Ripartizionepesi“B”
Fig.15 Weightdistribution“B”
14
A
B
C
D
Min.(mm) Max.(mm)
A - 3000
B 100 -
C - 2000
D 1000 -
E - 2400
E
