Pag. 6
A
B
POSIZIONI VITI DI FISSAGGIO - "L" BRACKETS MOUNTINGBA
80 mm20 mm
80 mm30 mm
130 mm30 mm
130 mm50 mm
TAB 3.1.3
R99
R99
R99
R99
ATTUATORE - ACTUATOR
ATTUATORE - ACTUATOR
ATTUATORE - ACTUATOR
ATTUATORE - ACTUATOR
