Type K J Thermometer
bit3:1→sub window value is OL , 0→not OL
bit4:1→sub window value is minus, 0→sub window value is plus.
bit5:1→6
th
byte and 7
th
byte represent #### 0→6
th
byte and 7
th
byte
represent ###.#
bit7 bit6:
00→Main window is T1-T2,sub window is T1
01→Main window is T1-T2, sub window is T2
10→Main window is T1, sub window is T2
11→Main window is T2, sub window is T1
4
th
BYTE:
first two BCD code of main window value.
5
th
BYTE:
last two BCD code of main window value
6
th
BYTE:
first two BCD code of sub window value.
7
th
BYTE:
last two BCD code of sub window value.
8
th
BYTE:
The last byte is the end byte , it value is 3, first and last
byte are used to check frame error.
