HX200HD-W-RS
The information contained in this document is believed to be correct, but OMEGA accepts no liability for any errors it contains and reserves
the right to alter specifications without notice.
HX200 Series
QUICK STARTUP GUIDE
Installing the probe for compressed air and dryer applications.
For the HX200HD/HX200HD-RS
Install fitting on to probe fitting threads facing the probe’s filter.
Apply Teflon tape to the external threads of the fitting.
Slide probe to desire depth. Note: be sure sinter filter is clear of the ferrule on the NPT fitting,
hand tight and then use a wrench a do a quarter turn,
Check for leaks, if leaks occur tightened down on fitting another 1/8” turn until leaks have been
To Next Page
