11
Seal Kit (G2501S-074) Contents
Item Description Qty
3 Filler Plug 1
4 O-ring, D7.1 x 2.65 1
A O-ring, D116 x 4 2
B O-ring, D73.8 x 3.5 1
C Back-up Washer 1
D U-cup 1
Item Description Qty
E Back-up Washer 1
F O-ring, D53 x 5 1
G Packing 1
H O-ring, D15 x 2.65 2
I Back-up Washer 2
J Packing (for 22050C only) 1
Item Part No. for 22050C Part No. for 22051C Description Qty
1 G251-20008-000 Filter 1
2 G250-20002-000 Reservoir 1
3 5905-00100-200 Filler Plug 1
4 5901-00071-000 O-ring, D7.1x2.65 1
5 G250-20004-000 Release Valve 1
6 G250-24000-000 Hyd Cartridge 1
7 B300-14002-000 Washer 1
8 G651-31002-000 Pump Cylinder 1
9 G651-31001-000 Pump Piston 1
10 G250-23000-000 Hyd Cartridge 1
11 G250-80000-000 Universal Joint 1
12 G251-00005-000 Spring 1
13 5405-12036-000 Pin 2
14 5405-02028-000 Retaining Pin 2
15 G250-50000-000 Piston Link 1
16 G251-00004-000 Return Spring, Pedal 1
17 5110-06016-000 Screw 1
18 G251-00009-000 Foot Pedal 1
19 G251-00010-000 Handle Fork 1
20 5304-00018-000 Snap Ring 2
21 G251-00003-000 Return Spring 2
22 5304-00028-000 Snap Ring 2
23 G251-00002-000 Saddle 1
24 5110-06010-000 Screw, Phillips 4
25 G250-00002-000 Cover 1
26 G251-40001-000 Knob 1
27 5402-04028-000 Spring Pin 1
28 N/A A070-40009-000 Hose clip 1
29 5110-04012-000 Screw, Phillips 1
30 5105-05012-000 Screw 1
31 G250-90009-K02 G250-90009-K01 Hyd Power Unit 1
32
N/A
A20060-0006 Air Hose 1
33 A27060-0003 Air Motor 1
34 A20060-0007 Lift Control Valve 1
35 A20060-0015 Hose Assembly 1
36 A20060-0016 Quick coupler, Male 1
37 G250-40000-000 Handle Assembly 1
38 G250-90004-K01 Front Wheel Assembly 2
39 G250-90004-K02 Caster Assembly 2
40 G250-90009-K03 Bolt Assembly 1
41 G651-31000-000 Pump Assembly 1
42 G251-00007-000 Handle Grip 2
- G2501S-074 ( includes 3,4 & A to J) Seal Kit for Hyd Unit 1
-
N/A
A27010-0000 Seal Kit for Air Motor 1
- A27010-0008 Piston for Air Motor 1
