Omega 21032 User Manual

7
Item Part No. Description Qty
1 5905-00100-100 Oil Filler Plug 1
2 G931-07014-100 Pump Piston 1
3 G931-08003-000 Release Valve Connecting Bar 1
4 G931-08002-000 Release Valve Gear 1
5 5206-00010-000 Nut M10 1
6 5303-00010-000 Lock Washer 2
7 5102-10016-000 Bolt M10 x 16 1
8 G931-00009-000 Return Spring, Handle Fork 1
9 G070-00008-100 Pin 1
10 G070-05001-000 Handle Fork 1
11 G931-00003-000 Return Spring 2
12 G93P-01000-000 Saddle 1
13 G934-00003-000 Handle Fork Bolt, Left 1
14 G931-00011-000 Handle Fork Bolt, Right 1
15 5303-00020-000 Lock Washer 2
16 G931-00010-000 Bolt M12 4
17 5301-00020-000 Washer 2
18 5305-00015-000 E-ring 2
19 G890-04100-100 Release Valve 1
20 G831-04000-000 Handle Assembly 1
21 G520-90026-K02 Caster Assembly 2
22 G890-90037-K01-04 Front Wheel Assembly 2
23 G83X-90010-K01 Hydraulic Power Unit 1
24 G831-03200-000 Air Motor 1
25 G831-03400-000 Air Hose Assy 1
26 G831-00001-000 Cover Plate 1
27 G831-03500-000 Air Inlet Swivel 1
28 A20060-0016 Quick Coupler, Male 1
29 A20060-0007 Lift Control Valve 1
30 G83X-90009-K01 Seal Kit (incl items 1, and a - m) 1
Seal Kit Contents:
Item Description Qty.
1 Oil Filler Plug 1
a O-ring 2
b O-ring 1
c Ram bearing 1
d Back-up washer 1
e U-cup 1
Item Description Qty.
f O-ring 1
g washer 1
h Back-up ring 1
j O-ring 1
k Back-up ring 1
m O-ring 1
