Omega 21032 User Manual

9
Item Part No. for 22040C Part No. for 22041C Description Qty
1 G251-20008-000 Filter 1
2 G423-20003-000 Reservoir 1
3 5905-00100-100 Filler Plug 1
4 5901-00071-000 O-ring, D7.1 x 2.65 1
5 G251-20004-000 G250-20004-000 Release Valve 1
6 G100-43000-000 Hyd Cartridge, Manual 1
7 B300-14002-000 Washer 1
8 G651-31002-000 Pump Cylinder 1
9 G651-31001-000 Pump Piston 1
10 N/A G100-44000-000 Hyd Cartridge, Air 1
11 G423-02000-000 G423-70000-000-04 Universal Joint 1
12 G251-00005-000 N/A Spring 1
13 5405-12039-000 Pin 1
14 5405-02028-000 Retaining Pin 2
15 G423-40000-000 Piston Link 1
16 G100-00015-000 Return Spring, Pedal 2
17 5102-06015-000 Screw 1
18 G251-00009-000 Foot Pedal 1
19 G251-00010-000 Handle Fork 1
21 G423-00011-000 Return Spring 1
23 G423-00013-000-04 Saddle 1
24 5111-55020-000 Screw, Phillips 4
25 G423-00010-000 Cover 1
26 G251-40001-000 Knob 1
27 5402-04028-000 Spring Pin 1
28
N/A
A070-40009-000 Hose clip 1
29 5110-04012-000 Screw, Phillips 1
30 5110-05025-000 5107-05016-000 Screw 1
31 G423-20000-000 G423-60000-000 Hyd Power Unit 1
32
N/A
A20060-0006 Air Hose 1
33 A27060-0003 Air Motor 1
34 A20060-0007 Lift Control Valve 1
35 A20060-0015 Hose Assembly 1
36 A20060-0016 Quick coupler, Male 1
37 G251-40000-000 G100-90009-K01 Handle Assembly 1
38 G423-90004-K01 Front Wheel Assembly 2
39 G250-90004-K02 Caster Assembly 2
40 G250-90009-K03 Bolt Assembly 1
41 G651-31000-000 Pump Assembly 1
42 5405-12050-000 Pin 1
43 5307-00012-000 Washer 2
44 5404-04030-000 Retaining Pin 2
45 5205-00005-000 N/A Nut 1
- G4230S-088 (includes 3,4 & A to J) Seal Kit for Hyd Unit 1
-
N/A
A27010-0000 Seal Kit for Air Motor 1
- A27010-0008 Piston for Air Motor 1
