PARTS AND FUNCTIONS
No. Part Name Function
1 PUSHER
WHEN ADDING INGREDIENTS, PUSH AND PRESS THE
INGREDIENTS LIGHTLY WITH THE PUSHER DOWN INTO THE
HOPPER TO IMPROVE JUICING EFFICIENCY
2 TOP COVER WITH CHUTE
COVERS BLADE AND MOTOR.
FEED INGREDIENTS DOWN THE CHUTE
3 FILTER BASKET SEPARATES JUICE FROM PULP
4 FILTER BASKET HOUSING
CATCHES AND EJECTS PULP AND FLOWS JUICE TO DRINKING
CONTAINER
5 JUICE NOZZLE JUICE FLOWS OUT INTO CUP
6 SAFETY LATCH SAFETY FEATURE THAT LOCKS PARTS IN PLACE FOR JUICING
7 MOTOR WHEEL DRIVER OF CENTRIFUGAL SPIN
8 POWER KNOB CONTROLS THE POWER OF THE JUICER
9 BODY
ELECTRICAL MOTOR IS HOUSED IN THE BODY
DO NOT IMMERSE IN WATER
10 PULP CONTAINER
CATCHES PULP EJECTED DURING JUICING
PROCESS
5 6
